Description
allowfullscreen="
Feature:
■PLC Touch Panel, user-friendly operation system.
•The streamline shape can reduce the wind disturbance noise and vibration.
•Machine returns back to original position once fabric runs empty.
•The machine power will automatically shut off up 5 minutes idle.
•The spread and laid fabric is not pulled when the emergency stop triggers.
•Simple operation increases production efficiency and also ensures the best quality.
•The platform combined with machine. So it won't affect the speed of the machine.
Main Device:
■Touch panel display
■Fabric loading sensor
■Edge control device
•Automatic lifting device
Optional:
•1/4 Turn Device
•Riding Platform with Track
•Safety Sensor Device
Specification
|
Model |
Y5-100 |
Y5-120 |
|
Power Supply |
1P/220V |
|
|
Motor |
600W |
|
|
Maximum Cloth Width |
330-1000mm/(13-39") |
330-1200mm/(13-47") |
|
Table Width |
1240mm |
1440mm |
|
Weight of cloth roll |
85kg max |
|
|
Travel Speed |
90m/min max |
|
|
L*W*H Dimensions(mm) |
1660*1440*1200 |
1860*1400*1200 |
|
L*W*H Packing Volume(mm) |
1960*1600*1400 |
2100*1600*1400 |
|
N.W/G.W |
2207370kg |
240/380kg |
|
Lay Height |
220mm |
|
|
Standard Width |
26" 32" 38" 44"(Available For Customization) |
|
|
Material Forms |
Fold Fabrics |
|
|
Gear Track |
12" Sections ( Required) |
|
|
Spreading Methods |
Zigzag Spreading (Face To Face) |
|
